Specifications

ProcessorMotorola 68A09P
Processor Clocking Speed1.6MHz (from a 6MHz external Xtal)
RAM1KB
ROM8KB
SoundAY3-8913 (3 channels)
Speaker3" cone speaker(Built-in)
Game ROM Address spaceUp to 64KB (2 x 32KB)
MB/GCE Game ROMsTypically 4KB or 8KB
Homebrew Game ROMsTypically 32KB or 64KB
ScreenBuilt in
Screen ColourCRT Black & White (pseudo colour with addition of coloured 6.43 x 8.21 inch overlays)
Screen Dimensions5 x 8 Inches
Screen Resolution256 x 256 vector start/stop points (Using standard timing)
Input/Output2 x ports. Each port offers 2 analogue input channels and 4 programmable inputs or outputs
